LD1621R-001 6W/9W Round LED Spot lights 55mm Cuthole Tilt With Multi Color Reflector
Voltage：
220-240V AC
Rated Power：
9W
LED：
Bridgelux COB
CCT：
2700K/3000K/3500K/4000K/5000K
CRI：
＞90
System Lumen(lm)：
600lm
Beam Angle：
15°/24/36°/60°
Power Factor：
＞0.9
SDCM：
＜3
IP Rating：
20
Nominal Lifetime：
50,000Hrs (L80 / B10)
Working Temperature：
-20℃~+40℃
Warranty：
5 Years
Dimming：
Triac; DALI; 0-10V
Specification
Data sheet
IES Test Report
Certification
Item No.：
LD1621R-001
Wattage：
9W
Color temperature：
2700K/3000K/3500K/4000K/5000K
System Lumen：
600lm
CRI：
＞90
Beam Angle：
15°/24/36°/60°
IP Rating：
20
LED Type：
Bridgelux COB
Warranty：
5 Years
Lifetime Expectancy：
50,000Hrs (L80 / B10)
SDCM：
<3
UGR：
<19
Power Supply：
Remote Class II Flicker Free Driver
Voltage：
220-240V AC
Frequency：
50-60Hz
Working temperature：
-20℃~+40℃
Product Dimensions：
Ø45.5x71mm
Cutout：
Ø55mm
Fixture Color：
Black / White
Product Materials：
Aluminium+PC
Unit Weight：
Fitting Protection Classification：
Class II
Intelligent Control：
On/Off; Triac; DALI; 0-10V
Mounting Options：
Recessed
